We ask Grok to review and provide a summary of the following pdf file titled "Class A Water Matters" on NSF/ANSI 55 and Class A and Class B UV Disinfection Systems.

https://solmetex.com/wp-content/uploads/2023/09/Class_A_Water_Matters.pdf

We created this post because it is our experience that up to 50% of private well owners need a UV disinfection system and many times the wrong UV disinfection system is installed. For city water users, it is not common to install UV disinfection because the water is coming from a community water supply that is treated and has a chlorine or disinfection residual, but in some cases this level of treatment is necessary.

The Sponsor for this Article is Jase Medical
“Emergency Medications & First Aid Kits”

Summary of "Class A Water Matters" (Water Conditioning & Purification, May 2010) by Grok with additional comments by the Know Your H20 Team (red). This article, authored by Rick Andrew of NSF International, provides an in-depth look at ultraviolet (UV) disinfection systems for point-of-use (POU) and point-of-entry (POE) drinking water treatment, with a focus on the NSF/ANSI 55 standard. It explains the technology’s role in inactivating pathogens and clarifies the differences between Class A and Class B systems, emphasizing why Class A certification is crucial for treating microbiologically unsafe water.

Key Concepts

• UV Technology Basics: UV light at 254 nm wavelength disrupts microbial DNA, preventing reproduction. It’s chemical-free, effective against bacteria, viruses, Giardia, and Cryptosporidium, but works best on clear (non-turbid) water.


• UV Disinfection (also known as Ultraviolet Germicidal Irradiation or UVGI) is a physical, chemical-free method that uses short-wavelength ultraviolet light to inactivate or kill microorganisms such as bacteria, viruses, protozoa, spores, and cysts by damaging their DNA or RNA, preventing replication.
• NSF/ANSI 55 Standard: Certifies UV systems for safety and performance. It addresses design, dosage, alarms, flow control, materials, structural integrity, and labeling.


• Class A Systems (Minimum UV dose: 40 mJ/cm² at the alarm set point): Designed to inactivate or kill bacteria, viruses, and protozoan cysts (including Cryptosporidium and Giardia) in contaminated water (microbiologically unsafe sources). These are suitable for primary disinfection of potentially unsafe water. They typically require fail-safe features like alarms or automatic shut-off if the UV dose falls below the required level.


• Class B Systems (Minimum UV dose: 16 mJ/cm²): Intended as supplemental treatment for already disinfected (microbiologically safe) public or private water supplies. They reduce non-pathogenic (nuisance) bacteria but are not for treating contaminated water or making specific cyst or virus claims.

Free Pdf copy of Educational Booklet (Our Drinking Water) or Order a Hardcopy

Table 1. Class A vs. Class B Systems.

Technical Requirements

• Dosage Verification: Bioassay tests confirm effectiveness at highest flow rates.


• Material Safety: Extraction tests ensure no harmful leaching; formulation reviews guide testing.


• Structural Integrity: Rigorous pressure tests (e.g., 240 psi burst for small vessels; 10,000 cycles at 50 psi for cyclic stress) simulate long-term residential use.


• Product Literature: Mandatory clear instructions, data plates, performance sheets, and replacement guides to inform users.

Importance and Benefits of Class A Treatment

• Public Health: Essential for homes relying on untreated sources, reducing waterborne disease risks without chemicals or taste changes.


• Regulatory Edge: Meets strict NSF criteria for efficacy and durability, building consumer trust.


• Limitations: Best for clear water; turbidity reduces effectiveness, requiring pre-treatment. (Pretreatment may be needed for water that has a high hardness, elevated levels of iron / manganese, or scale forming water and additional water quality testing would be advisable.)

Conclusions

The article stresses that Class A systems offer robust protection for at-risk water supplies, while the NSF/ANSI 55 standard ensures transparency and reliability, especially for water wells with a bacterial problem. It urges manufacturers to comply fully to avoid misleading claims, promoting UV as a vital, accessible disinfection tool. (Source: solmetex.com)

You may need a Class A Disinfection System

1. Well with elevated level of total coliform (i.e., 1 or more colonies per ml) with or without E. coli and/or an elevated presence for heterotrophic bacteria (i.e., > 250 colonies per ml).

2. You may consider using a Class B UV disinfection system when you have well water or city water that has a total coliform count of not-detectable or less than 1 colony per 100 ml and/or a heterotrophic bacterial count of < 250 colonies per 1 ml.

Common City Water Situations that Require UV Disinfection

1. A city water system that is having difficulty maintaining disinfection residuals.

2.The user is located near a dead-end in the water distribution system or part of a distribution network that has a lot of intermittent water usage.

3. A user that is experiencing issues or problems with bacterial regrowth in their portion of the distribution system. They may notice the water has a strange foul odor, back of toilet tank may have microbiological sheen or slimy coatings, and their water may have an off-taste.

4.Always make sure to get your water tested. Well Water / City Water Testing Options.

Since originally publishing this blog post, we have been asked 3 same questions.

Question 1: Does the Pulsar Ultraviolet Disinfection System | 10-20 GPM 405-PUV-200-BGF meet NSF 55 standards?

The answer is that it does not, but it does meet NSF/ANSI Standard 42.  No, the 405-PUV-200-BGF (Pulsar Ultraviolet Disinfection System, part of the 405-PUV-200 series from US Water Systems) is not a certified Class B (or Class A) disinfection system under NSF/ANSI 55. The system may meet the goals and merits of NSF 55-Class B, but the system has not been actually certified to the NSF 55 standard.

• Suitable for: City water or already-treated supplies needing extra protection against occasional microbes (similar to a Class B intent). It is not recommended as primary disinfection for private wells, surface water, or microbiologically unsafe sources without additional treatment and testing.


• Many non-NSF UV systems like this are still effective in real-world use if properly sized, maintained, and paired with pre-filtration. However, they lack independent verification of dose delivery and microbial inactivation that are required when NSF-55 certification is required for a regulated use, such as for a public water system.

Question 2: Do Quantum Disinfection Systems meet NSF 55 standards?

No, for two reasons: First, Quantum Disinfection is not a UV disinfection approach or system and NSF 55 applies to certified UV disinfection systems. Secondly, Quantum Disinfection (QD) is a water treatment technology that uses specially engineered nano-composite materials (often called Quantum Crystals or media) to instantly kill bacteria and other microorganisms through a catalytic electron-exchange process, without chemicals, electricity, or power.

Quantum Disinfection is best used on water that has already been treated and disinfected and the primary purpose is to use as a final barrier filtration method or to protect water treatment components that can be vulnerable to bacterial regrowth, like Reverse Osmosis and other membrane-based or deionization systems or additional water filtration for an RV that is getting water from a regulated RV Park.

Question 3: Are all Hallett Potable Water UV Systems NSF 55 Class A certified?

NO, the Hallett UV Pure UV For Potable Water Flows Up to 16.5 GPM - Model 500PN (406-500PN / 406-500PN-N) is certified to NSF/ANSI 55, but units labeled as 500P are not.

Key Certification Details

• NSF/ANSI 55 Class A: This is the higher tier certification for primary disinfection of microbiologically unsafe/contaminated water. It verifies the system can deliver a minimum UV dose of 40 mJ/cm² (at the alarm set point) and achieve significant log reduction of bacteria, viruses, Cryptosporidium, and Giardia.


• The “PN” designation indicates the NSF-certified potable water version (with performance validation). The “-N” in the SKU (e.g., 406-500PN-N) appears as a product variant/option on the official listing page for this NSF-certified model.


• It also meets NSF/ANSI 61 (drinking water system components – health effects) and NSF/ANSI 372 (lead-free).


Learn More about UV Disinfection
